Quick Details

  • Condition: New
  • Machine Type: Cutting Machine
  • Bag Type: T-shirt Bag
  • Material: Plastic
  • Computerized: Yes
  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: SANBI
  • Model Number: SHXJ-B600/800/1000/1200
  • Voltage: 220V 50Hz single phase
  • Power(W): 3-8kw
  • Dimension(L*W*H): 3000X1300X2000mm
  • Weight: 700-1300KGS
  • Certification: CE,ISO9001:2000
  • Warranty: 1 YEAR
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Name: 2017 Shopping Plastic Nylon Bag Making Machine
  • Model: SHXJ-B600/800/1000/1200
  • Bag Width: 100-1200mm
  • Bag length: 100-2000mm
  • Bag thickness: 0.02-0.20mm
  • Computer: Include
  • Servo motor: Optional device
  • Conveyor: optional device
  • Bag Kind: Shopping T shirt bag or flat bag
  • Certificate: CE,ISO9001;2000

Packaging & Delivery

Packaging Details Shopping Plastic Nylon Bag Making Machine :
standard wooden pallet or naked with stretch film packing .
Delivery Time Shopping Plastic Nylon Bag Making Machine :20 days
Product Description

Product Application


Shopping plastic Nylion Bag-making Machine has such functions as photoelectric automatic tracking microcomputer length setting, high limit stopping, automatic counting, automatic alarm on reaching the set value, high compensation accuracy with such characteristics as neatbags, little error and high automatic of whole machine, so it is a kind of ideal equipment for producing blank bags, colour bags, flat bags and vest bags, etc. And other various plastic soft packing bags.

Features:

1. Computer control over the entire process. 2. From film roll to final bag, one process flow.

3. Step motor (optional Servo motor), makes it easy to adjust the bag length and the production speed.

4. Automatic film feeding, coordination free from tension adjustment.

5. Automatically stop when film feeding blocks or bags jam.

6. High production efficiency to save manpower and time.

7. Equipment with heat sealing and cold cutting device

Model
SHXJ-B600
SHXJ-B800
SHXJ-B1000
SHXJ-B1200
Name
Shopping Plastic Nylon Bag making Machine
Max width of sealing &cutting(mm)
550mm x2 pc ,220mm x4 pc
750mm x2 pc ,320mm x4 pc
950mm x2 pc ,420mm x4 pc
1150mm x2 pc ,520mm x4 pc
Max length of sealing & cutting(mm)
1200mm
1500mm
1500mm
2000mm
speed of bag-making (m/min)
10-130pc/min
Number of strip(pc)
2 line or 4 lines
Photocell
1 pc
Step motor
Include
Power of main motor(kw)
1.5kw
2.2kw
2.2kw
3kw
Bag kind
 T shirt bag and flat bag
Weight(kg)
700
900
1100
1300
Outline dimension(L x w x h)mm
3000x1200x2000
3000X1600X20000
3000x2000x2000
3200x2200x2000

Main Features

1) Packing in one whole unit  and providing the manual and electric diagram ,easy in installation and maintation.

2) Adopting advanced world famous brand  in electric parts , main motor and inverter .

3) 4 pc unwinder station to make  bigger two line or smaller four lines at one time.

4) WIth auto conveyor unit to transportation the finished products automatically

5)more than 27 years history in manufacturing bag making machine  to make more specialized machine and provide good after -sale service.

Certifications
Factory Picture
Our Service
Packing & Delivery
Packaging
Size
123 (L) * 456 (W) * 789 (D)
Weight
1.2 T



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Packaging
Size
123 (L) * 456 (W) * 789 (D)
Weight
1.2 T



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
